Pure Sine Wave Inverter Chargers
3000 Watt Pure Sine Wave Power Inverter with Battery Charger and Auto Transfer Switch 12V to 120V
- Model
- PSW-3000
- Brand
- Royal Power
$899.99USD
Availability on request
Stock for this model has not been confirmed yet. We contact you before shipping if anything is delayed.
Specification needs confirmation
- Source conflict: the product title says 12V to 120V, but the legacy URL says 24V DC / 120-240V AC. Input and output voltage need confirmation.
- Input: 12V DC
- Output: 120V AC
- Continuous output: 3000 W
- Surge: 9000 W
- Waveform: Pure Sine Wave
- Built-in charger with transfer switch
Payment is handled by PayPal. Shipping is calculated at checkout. Shipping information
Description
0
Features
- 3000 watts continuous power
- 9000 watts peak power
- Provides 25 Amps - DC input voltage: 10.5-15V
- Anodized aluminum case provides durability
- Charger 35/70 Amp
- Built-in Cooling Fan
- Internal, Replaceable 30Ax12 spade-type Fuses
- Hardwire Kit and 120V AC output
- Overload Indicator - Digital Amp~Wattage display Helps monitor overloads
- Power ON/OFF Switch - Remote Port
- Built-in Battery Charger & Automatic Transfer Switch
- 3 FT Battery Cables Included
Specifications
Taken directly from the manufacturer data for this model. Blank values are not estimated from similar models.
| Model / SKU | PSW-3000 |
|---|---|
| Brand | Royal Power |
| Input voltage | 12V DC |
| Input range | 10.5-15 VDC |
| Output voltage | 120V AC |
| Continuous output | 3000 W |
| Surge output | 9000 W |
| Output waveform | Pure Sine Wave |
| Efficiency | Up to 95% |
| Battery charger | Yes — with automatic transfer switch |
| Dimensions | 12.4 x 7.5 x 26.4 |
| Weight | 70.8 lbs |
| Warranty | 1 year |
| Optimum efficiency | Up to 95% |
| No-load draw | < 0.8 amp (12V) |
| Output Wave Form | Pure Sinewave |
| Input voltage range | 10.5-15 VDC |
| Over voltage shutdown | Over 15 VDC |
| Under voltage shutdown | Under 10.5 VDC |
| Low voltage alarm | Audible |
| Overload shutdown | Yes |
| Thermal shutdown | Yes |
| Short circuit shutdown | Yes |
| Transfer Switch | 40 Amp |
| Inverter weight | 70.8 lbs |
| Dimensions (W x H x D) | 12.4 x 7.5 x 26.4 |
Manuals
The printed owner's manual ships with the unit. Request a PDF copy for this model at info@dcacpower.com.
Warranty
1 year
Shipping
Rates are calculated at checkout from your delivery address. Details
Questions about this model
- What battery voltage does the 3000 Watt Pure Sine Wave Power Inverter with Battery Charger and Auto Transfer Switch 12V to 120V need?
- This model is built for a 12V DC input. Never connect it to a battery bank of a different voltage.
- What is the difference between continuous and surge output?
- Continuous output is the power this unit can supply indefinitely (3000 W). Surge output (9000 W) is a brief peak for motor start-up only, and cannot be used as a running rating.
- How is this shipped?
- Shipping is quoted at checkout based on your address. See our shipping page for current rates and handling times.
